EISCO offers a wide range of educational microscopes. The build quality of the Redline series is superior and comparable to high-end microscopes, but at an affordable price.

Eyepieces: WF 10x widefield eyepiece. Monocular models have an eyepiece with a built-in pointer. Binocular models come with a diopter adjustment for an eyepiece holder.

Observation Tube: Monocular or binocular Siedentopf-type head, rotatable 360°. Tube length: 160 mm.

Bridge: Inverted bridge for 4 objectives. Ball-bearing mechanism and click-stop.

Objectives: Color-coded DIN achromatic objectives. 40x and 100x oil-filled objectives are spring-mounted.

Protection: Built-in protection for the specimen and objective.

Stages: Single stage 120×120 mm or 130×130 mm stage with a double-layer mechanical X-Y stage. The mechanical X-Y stage travels 70×28 mm.

Focus Control: Coaxial coarse and fine adjustment knobs on both sides with 0.002 mm graduations. The focus friction control is adjustable.

Condenser: Height-adjustable N.A. 1.25 Abbe condenser with iris diaphragm and filter holder.

Illumination: 1-watt LED illumination with internal power supply (85-230V).

Packaging: Complete with spare fuse and dust cover in a polystyrene box.
